| Products - Spiral
Wounded |
Spiral
wound gasket is manufactured by spirally winding
a pre-formed metal strip and filler on the outer
peripery of metal winding mandrels. The winding
mandrel outside diameter forms the innner diameter
of the gasket and the lamination are continually
wound until the outer diameter is attaineds.
The inner and outer diameters is reinforced with
several plies of metal with no fillers being introduced.
This gives greater stability and provides better
compression and sealing characteristics. Then by
varying the ratio of the filler to the metal plies
for a given gasket width density, and hence the
compressibilty, can be controlled.
1. Spiral wound gasket without inner and outer ring
suitable for tongue and groove flange and narrow
width flange.
2. Spiral wound gasket with outer ring which accurately
centers gasket on flange and acts as compression
stop.
3. Spiral wound gasket with inner and outer ring,
innner ring gives an additional compression limiting
stop and provides heat and corrosion barrier protecting
gasket winding and flange erosion.
4. Spiral wound gasket with metal jacketed partition
bar welded to spiral wound gasket for use on heat
exchanger. |
| |
Available
Material
Metal Winding Strip:Stainless Steel Type 304,
304L, 316, 316L, 321, 347, 410, Inconel 600, Monel,
Titanium, Incoloy 800.
Filler Material: Compressed Asbestos, Flexible
Graphite, PTFE, Ceramic.
Guide Ring Material: Carbon Steel, S.S. Type
304, 304L, 316, 316L, 321, 347, 410, Inconel 600,
Monel, Titanium, Incoloy 800. |
| |
|
Dimensional
Data to ASME B16.20
To Suit ASME /
ANSI b16.5 Flanges
|
|
|
|
NOM
PIPE
SIZE
|
CLASS
150,300
400,600
|
CLASS
900,1500
2500
|
CLASS
150
|
CLASS
300
|
CLASS
400
|
CLASS
600
|
CLASS
900
|
CLASS
1500
|
CLASS
2500
|
CLASS
150
|
CLASS
300
|
CLASS
400
|
CLASS
600
|
CLASS
900
|
CLASS
1500
|
CLASS
2500
|
|
1/4
|
22.2
|
-
|
12.7
|
12.7
|
12.7
|
12.7
|
-
|
-
|
-
|
44.5
|
44.5
|
44.5
|
44.5
|
-
|
-
|
-
|
|
1/2
|
31.8
|
31.8
|
19.1
|
19.1
|
19.1
|
19.1
|
19.1
|
19.1
|
19.1
|
47.8
|
54.1
|
54.1
|
54.1
|
63.5
|
63.5
|
69.9
|
|
3/4
|
39.6
|
39.6
|
25.4
|
25.4
|
25.4
|
25.4
|
25.4
|
25.4
|
25.4
|
57.2
|
66.8
|
66.8
|
66.8
|
69.9
|
69.9
|
76.2
|
|
1
|
47.8
|
47.8
|
31.8
|
31.8
|
31.8
|
31.8
|
31.8
|
31.8
|
31.8
|
66.8
|
73.2
|
73.2
|
73.2
|
79.5
|
79.5
|
85.9
|
|
1
1/4
|
60.5
|
60.5
|
47.8
|
47.8
|
47.8
|
47.8
|
39.6
|
39.6
|
39.6
|
76.2
|
82.6
|
82.6
|
82.6
|
88.9
|
88.9
|
104.9
|
|
1 1/2
|
69.9
|
69.9
|
54.1
|
54.1
|
54.1
|
54.1
|
47.8
|
47.8
|
47.8
|
85.9
|
95.3
|
95..3
|
95..3
|
98.6
|
98.6
|
117.6
|
|
2
|
85.9
|
85.9
|
69.9
|
69.9
|
69.9
|
69.9
|
58.7
|
58.7
|
58.7
|
104.9
|
111.3
|
111.3
|
111.3
|
143.0
|
143.0
|
146.1
|
|
2 1/2
|
98.6
|
98.6
|
82.6
|
82.6
|
82.6
|
82.6
|
69.9
|
69.9
|
69.9
|
124.0
|
130.3
|
130.3
|
130.3
|
165.1
|
165.1
|
168.4
|
|
3
|
120.7
|
120.7
|
101.6
|
101.6
|
101.6
|
101.6
|
95.3
|
92.2
|
92.2
|
136.7
|
149.4
|
149.9
|
149.4
|
168.4
|
174.8
|
196.9
|
|
3 1/2
|
133.4
|
133.4
|
114.3
|
114.3
|
104.8
|
104.8
|
104.8
|
104.8
|
-
|
161.9
|
165.1
|
161.9
|
161.9
|
190.5
|
187.3
|
-
|
|
4
|
149.4
|
149.4
|
127.0
|
127.0
|
127.7
|
127.7
|
127.7
|
117.6
|
117.6
|
174.8
|
181.1
|
177.8
|
193.8
|
206.5
|
209.6
|
235.0
|
|
4 1/2
|
165.1
|
165.1
|
139.7
|
139.7
|
134.9
|
134.9
|
134.9
|
134.9
|
-
|
177.8
|
196.9
|
193.7
|
209.6
|
238.1
|
231.8
|
-
|
|
5
|
177.8
|
177.8
|
155.7
|
155.7
|
147.6
|
147.6
|
147.6
|
143.0
|
143.0
|
196.9
|
215.9
|
212.9
|
241.3
|
247.7
|
254.0
|
279.4
|
|
6
|
209.6
|
209.6
|
182.6
|
182.6
|
174.8
|
174.8
|
174.8
|
171.5
|
171.5
|
222.3
|
251.0
|
247.7
|
266.7
|
289.1
|
282.7
|
317.5
|
|
8
|
263.7
|
257.3
|
233.4
|
233.4
|
225.6
|
225.6
|
222.3
|
215.9
|
215.9
|
279.4
|
308.1
|
304.8
|
320.8
|
358.9
|
352.6
|
387.4
|
|
10
|
317.5
|
311.2
|
287.3
|
287.3
|
274.6
|
274.6
|
276.4
|
266.7
|
270.0
|
339.9
|
362.0
|
358.9
|
400.1
|
435.1
|
435.1
|
476.3
|
|
12
|
374.7
|
368.3
|
339.9
|
339.9
|
327.2
|
327.2
|
323.9
|
323.9
|
317.5
|
409.7
|
422.4
|
419.1
|
457.2
|
498.6
|
520.7
|
549.4
|
|
14
|
406.4
|
400.1
|
371.6
|
371.6
|
362.0
|
362.0
|
355.6
|
362.0
|
-
|
450.9
|
485.9
|
482.6
|
492.3
|
520.7
|
577.9
|
-
|
|
16
|
463.6
|
457.2
|
422.4
|
422.4
|
412.8
|
412.8
|
412.8
|
406.4
|
-
|
514.4
|
539.8
|
536.7
|
565.2
|
574.8
|
641.4
|
-
|
|
18
|
527.1
|
520.7
|
474.7
|
474.7
|
469.9
|
469.9
|
463.6
|
463.6
|
-
|
549.4
|
596.9
|
593.9
|
612.9
|
638.3
|
704.9
|
-
|
|
20
|
577.9
|
571.5
|
525.5
|
525.5
|
520.7
|
520.7
|
520.7
|
514.4
|
-
|
606.6
|
654.0
|
647.7
|
682.8
|
698.5
|
755.7
|
-
|
|
24
|
685.8
|
679.5
|
628.7
|
628.7
|
628.7
|
628.7
|
628.7
|
616.0
|
-
|
717.6
|
774.7
|
768.4
|
790.7
|
838.2
|
901.7
|
-
|
|
|
| |
|
|
